INGCO 800mm Professional Heavy-Duty Manual Tile Cutter – Tungsten Carbide Ball-Bearing Scoring Wheel (22x6x2mm), 16mm Max Cutting Thickness, Aluminum Die-Cast Handle, and Included Fabric Carrying Bag (HTC04802)

Cutting large-format ceramic, porcelain, and glazed tiles with low-grade manual cutters or improvised tools often leads to jagged edges, uneven snapping, and high material waste. Standard tile cutters frequently flex along the base or guide bars, causing scoring lines to drift out of alignment during long straight or diagonal cuts. The INGCO HTC04802 800mm Heavy-Duty Manual Tile Cutter is a professional-grade tiling tool engineered for smooth scoring, precise snapping, and straight/diagonal tile fitting. Built with a heavy 1015 x 200mm steel base and rigid sliding rails, this 800mm tile cutter delivers exceptional accuracy across dense porcelain and ceramic wall and floor tiles.

The effortless scoring action and long service life of this cutter stem from its tungsten carbide ball-bearing scoring wheel (22 x 6 x 2mm) and extra-long aluminum die-cast slider handle. Designed to slice cleanly through tile thicknesses up to 16mm, the smooth ball-bearing carriage glides with minimal friction along 20mm steel guide rods. Complete with a multi-function ruler for repeatable angled cuts and a heavy-duty fabric carrying bag, the HTC04802 provides total portability and precision for professional tiling contractors.

Key Features

• Generous 800mm Maximum Cutting Length – Accommodates modern large-format ceramic and porcelain floor/wall tiles up to 800mm.

• 16mm Maximum Cutting Thickness – High-leverage breaking system easily snaps thick, hard-glazed porcelain and dense ceramic tiles.

• Tungsten Carbide Ball-Bearing Wheel (22x6x2mm) – Ultra-durable scoring blade delivers crisp, continuous lines without skipping.

• Heavy-Duty Steel Base (1015 x 200mm) – 2mm thick reinforced steel platform provides a rigid, non-flexing surface for clean snapping.

• Smooth Ball-Bearing Carriage System – Sliding arms with integrated bearings travel along 20mm guide bars for friction-free scoring.

• Straight & Diagonal Cutting Capability – Integrated adjustable ruler guide allows for precise, repeatable parallel and 45° diagonal cuts.

• Fabric Carrying Bag Included – Heavy-duty canvas bag protects the machine and allows easy transport between job sites.

Technical Specifications

• Brand: INGCO

• Model: HTC04802

• Product Type: Manual Tile Cutter / Ceramic & Porcelain Scoring Machine

• Maximum Cutting Length: 800 mm

• Maximum Cutting Thickness: 16 mm

• Scoring Blade Size: 22 mm x 6 mm x 2 mm

• Scoring Wheel Material: Tungsten Carbide with Ball Bearing

• Base Plate Dimensions: 1015 mm x 200 mm (2mm Thickness)

• Slider Bar Diameter: 20 mm

• Handle Material: Ergonomic Aluminum Die-Cast

• Net Product Weight: Approx. 12.0 kg

• Packaging Presentation: Packed in a Color Box with Fabric Carrying Bag Included

• Primary Target Materials: Glazed ceramic tiles, vitrified floor tiles, porcelain, terracota, and glass tiles

• Primary Applications: Bathroom wall tiling, floor installation, kitchen backsplashes, commercial tile fitting, and renovation scoring

Ideal For

Professional tilers, flooring contractors, general builders, and serious DIYers needing a heavy-duty 800mm manual tile cutter for smooth, non-electric cutting of porcelain and ceramic tiles.

Package Includes

• 1 x INGCO HTC04802 800mm Tile Cutter Assembly

• 1 x Tungsten Carbide Ball-Bearing Scoring Blade (Pre-Installed)

• 1 x Multi-Function Angle Guide Ruler

• 1 x Protective Fabric Carrying Bag
